System Image Recovery - Can't find System Image

Anonymous

I am trying to restore a backup system image to my repaired PC. It is wiped clean. I have the "Repair Disc Windows 7 64 Bit" that I created in Windows 7. Using Windows 7 Backup I have a system image backup on an external WD Essentiasl 1TB USB Hard Drive.

I insert the Repair Disc and start the system. Get to System Recoevery Options. I have the external Hard Disk with the system backup image connected. Select System Image Recovery option. Says "Windows cannot find a system image on this computer. Attach the backup hard disk or insert the final DVD from a bckup set and click retry. Alternatively, close this dialog for more options. Retry gives me the same message. Tried starting with drive attached, not attached, same result. Click cancel.

Next option selected is "Select a system image." No system image listed. Hit refresh, still nothing. Top of screen says "Click Advanced to add a network location or install a driver for a backup device if it does not show up in the list below." I click on the Advanced tab. Option to "Search for a system image on the network" or "Install a driver." I select install a driver. Find the right driver for the WD Essential hard drive (disk.sys and partmgr.sys) and when I click on them I get "The specified location does not contain information about your hardware." Click OK. Can't find how to load these drivers I am being asked for.

Funny thing is that on the screen where I search for driver I can see the WD Essential Hard Drive connected to the system. I can also see the system image files but when I click on them I get the same error message, "The specified location does not contain information about your hardware."

Please HELP. This is very frustrating!!!

Locked Question. This question was migrated from the Microsoft Support Community. You can vote on whether it's helpful, but you can't add comments or replies or follow the question.

0 comments

Answer accepted by question author

Anonymous

While in Repair Mode, you have an option to open a Command Prompt. From there try the following commands:

Mountvol

(This command will show you all available drives, including your external disk)

dir Q:

(Replace Q: with one drive letter at a time from the letters that the mountvol command showed you, e.g.

dir D:

dir E:

etc.

until you see a folder "WindowsImageBackup" on the screen. Let's assume it is F:\WindowsImageBackup.

dir F:\WindowsImageBackup /s

(This command should show you the contents of the image folder, with files totalling more than 10 GBytes)

Now perhaps this image folder is missing, incomplete or inaccessible.

I have to add that I am disappointed with the native imaging facility under Windows 7. It is temperamental and its functionality is extremely limited. I recently bought myself a copy of Acronis TrueImage 10 and its is to the Windows imaging tool like a fully functional motor cycle is to a child's tricycle. Other brand imaging tools are just as functional - just make sure that they are certified for Windows 7.

0 comments

95 additional answers

Anonymous

2018-06-07T18:11:36+00:00

I am trying to restore a backup system image to my repaired PC. It is wiped clean. I have the "Repair Disc Windows 7 64 Bit" that I created in Windows 7. Using Windows 7 Backup I have a system image backup on an external WD Essentiasl 1TB USB Hard Drive.

I insert the Repair Disc and start the system. Get to System Recoevery Options. I have the external Hard Disk with the system backup image connected. Select System Image Recovery option. Says "Windows cannot find a system image on this computer. Attach the backup hard disk or insert the final DVD from a bckup set and click retry. Alternatively, close this dialog for more options. Retry gives me the same message. Tried starting with drive attached, not attached, same result. Click cancel.

Next option selected is "Select a system image." No system image listed. Hit refresh, still nothing. Top of screen says "Click Advanced to add a network location or install a driver for a backup device if it does not show up in the list below." I click on the Advanced tab. Option to "Search for a system image on the network" or "Install a driver." I select install a driver. Find the right driver for the WD Essential hard drive (disk.sys and partmgr.sys) and when I click on them I get "The specified location does not contain information about your hardware." Click OK. Can't find how to load these drivers I am being asked for.

Funny thing is that on the screen where I search for driver I can see the WD Essential Hard Drive connected to the system. I can also see the system image files but when I click on them I get the same error message, "The specified location does not contain information about your hardware."

Please HELP. This is very frustrating!!!
Was this answer helpful?

0 comments No comments
Anonymous

2018-05-20T15:14:32+00:00

What should I do to solve this problem
Was this answer helpful?

0 comments No comments
Anonymous

2018-04-07T07:12:46+00:00

I have back up disc but they are for the factory windows version 8.1. I upgraded to windows 10 from the web . I am attempting to set up back up but a I have only the backup on external hard drive in file history. will it have the same problem seeing it just ran
Was this answer helpful?

0 comments No comments
