Windows Security Windows only shows Shield Icon

Anonymous
2023-12-24T08:52:08+00:00

Split from this thread.

Hi Frank,

If you wish to fix Windows Security, please start a new thread and post the following logs. Post the link to the new thread here.

Step 1:

Step 2:

  • Download defender_diag.bat. Right-click on the file, click Properties, Unblock, and OK. Run the batch file as administrator.

(The Batch file queries Defender-related settings/Policies and outputs the results to a log file named defender.log. Upload this log to your OneDrive and share the link here.)

(How-To: Share OneDrive files and folders - Microsoft Support)

Windows for home | Windows 11 | Security and privacy

Locked Question. This question was migrated from the Microsoft Support Community. You can vote on whether it's helpful, but you can't add comments or replies or follow the question.

0 comments
Answer accepted by question author
Anonymous
2023-12-30T09:13:35+00:00

Those entries have no significance. Those entries show up in my system as well. You'll see a lot of Not Found entries for any operation you do. Usually, most of those entries have no significance.

You may try this if possible.

Download this REG file and save it to a folder named c:\reg\

Launch AdvancedRun (from Nirsoft) and start cmd.exe as TrustedInstaller.

In the TrustedInstaller Command Prompt, run:

  • reg.exe import c:\reg\securityhealth.reg
  • exit

This restores some essential registry keys used by Defender.

Was this answer helpful?

0 comments

94 additional answers

Sort by: Newest
Most helpful Newest Oldest
  1. Anonymous
    2023-12-28T13:10:57+00:00

    Hi Ramesh

    This did it!!!!!!! Thank you so much

    So replacing the securityhealth folder 1.0.2207.20002-0 with the zip you provided (in WinRE mode)

    then rebooting, and I checked, with services.msc and the windows security service is running, and when going into windows security, it loads the different icons


    I hope Frank will also gets his one resolved, at least this one did it for me. Thanks again!

    Anything else I need to do, I guess I can now remove the old 1.0.2207.20002-0 ? Just to avoid I'm filling up my harddrive with old non working components.

    BR and have a good start in 2024.

    Rob

    Was this answer helpful?

    0 comments
  2. Deleted

    This answer has been deleted due to a violation of our Code of Conduct. The answer was manually reported or identified through automated detection before action was taken. Please refer to our Code of Conduct for more information.

    Comments have been turned off. Learn more

  3. Anonymous
    2023-12-28T12:18:39+00:00

    (Assuming you did the first two things -- i.e., extracting the zip file to C:\SecurityHealth. & backing up "C:\Windows\System32\SecurityHealth\1.0.2207.20002-0" to another location.)

    To launch WinRE, click Start, Power, and then press and hold the Shift key while clicking Restart.

    In WinRE, click Troubleshoot, Advanced Options, and click Command Prompt.

    Run bcdedit and post the output here.

    Was this answer helpful?

    0 comments
  4. Anonymous
    2023-12-28T12:15:21+00:00

    Hi Frank,

    The instructions are for Robo4112. Please don't try that because you already have a newer platform folder. The zip archive is meant for Robo4112's system.

    Was this answer helpful?

    0 comments
